The machine consists of a high capacity circulation pump which is directly coupled to the motor and special reversing device fitted below the dyeing vessel for flow reversal. The pump is mechanically sealed and controlled by the flow rate of inverter. Dyeing Technique process is improved through the heat exchange between the liquid stream and liquor. An auxiliary vessel arrangement is composed of feed pump & mixing system. The liquor circulation rate is increased through steady state commutation without stopping main pump activity.
Features:
-
Adjustable pressure lid for less capacity dyeing
-
Economic in power Consumption when starting & de-loading
-
Accurate Pressure differential sensor to control liquor level.
-
Optional accessories like cover addition tank, temperature gauge, Level Indicator
These machines are suitable for short liquor dyeing process with good dyeing effect. It is used in pretreatment dyeing of loose fibers, bobbins etc.
We supply Yarn Dyeing Machines as per client’s specification.
Optional Accessories:
-
Cover
-
Addition tank
-
Kier
-
Temperature gauge
-
Feeding pump
-
Level Indicator
